Sinotruk 8X4 Concrete Mixer Truck

Price on request
REQUEST NOW

Product parameters

Engine model: WD615.47, Euro II, 371HP
Optional: WD615.62 / WD615.87 / WD615.69 / WD615.47
Overall Dimension:10820*2550*3900mm

Specification

Product Features

1. The tank body uses double helical blades that makes its density moderate, with symmetrical mixing board on the front taper place; double blades and guiding blades of discharge are installed on the outlet of tank, which makes the discharge more evenly, faster in speed, and convenient for the pumping transportation of other devices (such as automobile pump).

2. Low angle for mixing drum can extend the service life of hydraulic pump, motor and reducer. The sub frame uses high intensity square tube with damping in the central area that can play role when vehicle is at full load and under the bad conditions of road, which can lower the center of gravity of truck and make it move more smoothly.

3. The upload production of this mixer adopts multiple advanced technology, which can produce various types of mixer in volume such as 3m3, 5m3,6m3,8m3, 9m3,10m3, 12 m3 etc.

Truck Model	ZZ1317N3667A
ENGINE	Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.47, Euro II, 371HP With Oil Bath Filter System 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L Optional: WD615.62 / WD615.87 / WD615.69 / WD615.47
Cabin	HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber. High steel bumper, With inter-cooler fence Option: air suspension driver’s seat, high roof double bunk, fire extinguisher, warning light
Clutch	Single-plate dry coil-spring clutch, hydraulically operating with air assistance
Transmission	HW15710 / HW19710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle	HF9, 2 X 9000 KGS Steering with double T-cross section beam Optional:HF7, 2 x 7000kgs, drum type
Rear Axle	HC16,2 x 16000 KGS Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. Ratio::4.8 / 5.73 Optional:ST16,double reduction, speed ratio:3.93,4.42,4.8/ MCY13, 2 x 13000kgs
Chassis	Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Steering	ZF power steering, model ZF8118, hydraulic steering with power assistance
Overall Dimension	10820 * 2550 * 3900mm
Mixer tank effective volume	Size:16cbm With Italian brand Bonfiglioli reduction gears, America brand Eton oil pump and motor
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake Optional:EVB, ABS, AUTOMATICSLACK ADJUSTER
Tyres	12.00R20,Radial (steel wire) Tires,1 spare tyre Option: 12.00-20, 12R22.5, 315/80R22.5, 12.00R24
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Instrument Panel	Active check central control with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging.
Color	Optional

COMPANY ADVANTAGES:

1	Rich Experience in sale of the Sinotruk’s heavy equipment & truck.
2	Expert in kinds of heavy trucks and spare parts.
3	Personalized customization to meet your working requirements.
4	High quality of Original parts & OEM services.
5	Engineers and experts on call for pre/after sale support.
6	One-stop service with heavy trucks, parts as well as stand-by advice & support.


Q:HOW CAN YOU INSURE MY MONEY BE SAFE?

A:Firstly you can send the money via trade assurances,Secondly We have worked in the field of truck sale for many years,and we have served thousands of buyer all over the world,We take the reputation as our life.we won’t deduct any money if the business break down in the end.

Q:WHAT’S YOUR MOQ AND DELIVERY TIME?

A:Usually,our MOQ is 1 sets,and our delivery time is within 30days for new placed order, and for stocked trucks our lead time is within 5 workdays.

Q:CAN I CHOOSE THE TRANSPORTATION METHOD BY MYSELF?

A:Yes,of course.But if CIF, you choose a different ships,that means the price will be different,(the price of bulk cargo ship is different from RO-RO ship )so the price will be changed,please notice that.

Q:DO YOU SUPPLY SPEAR PARTS?

A:Yes,we can provide all parts of the truck,like engine parts,electric parts,truck body parts and truck cabin parts.

Q:HOW CAN WE GET AFTER SALE SERVICE ?

A:We SINOTRUK Group has many overseas after sale service center, you can get services in these center,Also we can provide you technical support and parts supply,.
